Crankbrothers Highline 7 150 Mm Dropper Post

crankbrothers Highline 7 150 mm dropper post – improved bike experience
The crankbrothers Highline 7 seatpost with 150 mm travel is a Dropper Post for Enduro, All-Mountain and Cross-Country use. It impresses with its stepless saddle height adjustment, smooth function, quick return adjustment and, last but not least, easy installation. Its core piece is a self-contained hydraulic IFP cartridge with two chambers and internal floating piston. Thanks to the 2-bolt clamp with quick release head, the saddle can be replaced quickly. The whole thing is rounded off by a Jagwire cable, Igus bearings and Trelleborg seals of the highest quality. Not least thanks to its remarkably low overall height, low weight and clean internal cable routing, the Highline 7 opens up a whole new biking experience.
Specifications:Application:Enduro, All Mountain, Cross CountryTravel:150 mmDiameter:30.9 mm, 31.6 mmLength:467 mmSetback:0 mmTechnical Information:Actuation:mechanical handlebar remoteCable Routing:internalClamp:2-bolt clampCompatible Saddle Rails:7 x 7 mm (standard)Material:aluminium (7075-T6)Approved For:Insertion Depth (max.):268 mmInsertion Depth (min.):100 mmFeatures:lower insertion depth suitable for many framespremium seals by Trelleborgexclusive plain bearings by IgusJagwire cable and cable housingencapsulated hydraulic cartridge (2 chambers: gas and oil separately) with internal floating pistoninternal cable routingquick connection mechanism for easy cable installationlinear actuator for quick returnquill made of machine weight-reduced aluminium (10-15 g less than Highline 3)standard 2-bolt clamp w/ quick release47 mm minimum construction height336 mm maximum extension length197 mm minimum extension lengthremote with especially flexible mount system available separately
Maintenance Intervals:
The maintenance intervals are dependent on riding style and geographical location.
After every ride: Wipe dust and dirt from the seatpost, focusing on the seal area and the tip of the coil spring. Check the seatpost for any damage.
Every 150-175 hours of riding time: Lubricate the internal components by unscrewing the collar, use coil-specific grease (never oil!) up to the sleeve under the collar and reassemble. Check screw connections for the specified torques.
450+ hours riding time: Check seatpost and replace internal components if necessary.
Models:30.9 mm / 467 mm / SB 0 mm:
Diameter:30.9 mmLength:467 mmSetback:0 mmManufacturer Number:16382
31.6 mm / 467 mm / SB 0 mm:
Diameter:31.6 mmLength:467 mmSetback:0 mmManufacturer Number:16383Contents:1 x crankbrothers Highline 7 150 mm dropper post1 x Jagwire cable1 x Jagwire cable housingOrder Together:The remote kit is required for use.
